AIR-AP300

COMMANDO AirONE 300Mbps, 2.4GHz, 802.11n, MIMO, Indoor Access Point

Data Sheet Config Guide Gallery YouTube

AIR-AP300

COMMANDO AirONE 300Mbps, 2.4GHz, 802.11n, MIMO, Indoor Access Point

Product Highlights

• Multiple Operational Modes like Gateway Mode, Repeater mode, WISP mode, AP mode (default mode is AP mode).

• Multi SSID up to 4 with inbuilt WI-FI channel analysis.

• Supports IEEE 802.11b/g/n 2.4GHz Wireless which having single band with radio RF Power up to 27dBm.

• Support wireless RF power adjustable as per user movements from AP.

• Access end users up to 64 max, with concurrent end users up to 50.

• Support tag VLAN and VLAN management.

• Supports intelligent load balance based on users.

• Support seamless roaming and low-rate terminal access.

• Dual purposes WAN or IEEE 802.3af Port (PoE) port supporting 1x 10/100Mbps.

• Dedicated LAN ports 1x 10/100Mbps.

• Supports Wi-Fi client distance 45 meters and above depending on surrounding conditions.

• Dual input for power either PoE or DC power inputs 12V, 1A.

• Support Open or encryption like WPA/WPA2PSK_TKIPAES.

• Plug and Play design simplifies installation with self-adaption.

• Compact, silent design perfect for noise sensitive environments.

• With Zero Touch Provisioning: Plug and play and no setup. Affordable, Easy-to-Use AP for Small Business Networks, with Zero Configuration Required.

• Built-in High-Performance Processor with long life, Suitable for Deployment of Large Scale Commercial Scenarios

• Comes with one-year default warranty – optionally extendable up to 3 years.

Software Highlights

Home

Device Information like CPU Usage, Memory Usage, LAN Information like IP Mode Get IP From AC/Gateway/Static, Status with 2G Wi-Fi, Clients Status with information like SSID, Channel, Bandwidth, Encrypt, MAC Address, Operation Mode configure like AP/ Fat AP Mode with Uptime, Flow in bps for AP Downstream and AP Up stream

Wizard

Gateway Mode, Repeater Mode, WISP Mode, AP Mode (Default Selection)

Wi-Fi

2G Wi-Fi Basic and VAP (1 to 3) ON/OFF, SSID, Hide your SSID, Bandwidth, Channel, Encryption Open/Encryption with WPA/WPA2PSK_TKIPAES, MAC ACL with Add, Delete, Apply with disable/Allow/ Prohibit option, Wi-Fi Timer Off/ON with Time Frame, Advanced setting like Country Region, 2G Channel (1-13), Multicast Fast, Maximum for per AP (Range 1-64), WLAN Partition, Short GI, Coverage Threshold(-95dBm~-65dBm), TX Power, DFS.

Network

LAN Settings with DHCP server option, Static DHCP, VLAN Settings, Cloud Server Settings

Manage

Configure, Reboot, Modify Password, Upgrade, Time, Log

https://www.commandonetworks.com//AIR-AP300

COMMANDO Networks - 0 / 0

AIR-AP300 -- COMMANDO AirONE 300Mbps, 2.4GHz, 802.11n, MIMO, Indoor Access Point

19 Sep 2023

How to Install and Configure Ceiling Wireless Access Point - COMMANDO AirONE AIR-AP300, 802.11n

23 Jan 2023

Click on image to expanded

AIR-AP300

COMMANDO AirONE 300Mbps, 2.4GHz, 802.11n, MIMO, Indoor Access Point

3 in 1 Access Point, 300 Mbps, 100 Users, 2.4 GHz, MIMO High Gain Omni 5dBi Internal Antenna, 16 MB Flash, 64 MB RAM, PoE Support, Dual Mode FIT and FAT, Operation Mode Gateway, Repeater, Wireless AP

Price & Availability:

{"highlights":"<div><span>\u2022<\/span> Multiple Operational Modes like Gateway Mode, Repeater mode, WISP mode, AP mode (default mode is AP mode).<\/div>\r\n<div><span>\u2022<\/span> Multi SSID up to 4 with inbuilt WI-FI channel analysis.<\/div>\r\n<div><span>\u2022<\/span> Supports IEEE 802.11b\/g\/n 2.4GHz Wireless which having single band with radio RF Power up to 27dBm.<\/div>\r\n<div><span>\u2022<\/span> Support wireless RF power adjustable as per user movements from AP.<\/div>\r\n<div><span>\u2022<\/span> Access end users up to 64 max, with concurrent end users up to 50.<\/div>\r\n<div><span>\u2022<\/span> Support tag VLAN and VLAN management.<\/div>\r\n<div><span>\u2022<\/span> Supports intelligent load balance based on users.<\/div>\r\n<div><span>\u2022<\/span> Support seamless roaming and low-rate terminal access.<\/div>\r\n<div><span>\u2022<\/span> Dual purposes WAN or IEEE 802.3af Port (PoE) port supporting 1x 10\/100Mbps.<\/div>\r\n<div><span>\u2022<\/span> Dedicated LAN ports 1x 10\/100Mbps.<\/div>\r\n<div><span>\u2022<\/span> Supports Wi-Fi client distance 45 meters and above depending on surrounding conditions.<\/div>\r\n<div><span>\u2022<\/span> Dual input for power either PoE or DC power inputs 12V, 1A.<\/div>\r\n<div><span>\u2022<\/span> Support Open or encryption like WPA\/WPA2PSK_TKIPAES.<\/div>\r\n<div><span>\u2022<\/span> Plug and Play design simplifies installation with self-adaption.<\/div>\r\n<div><span>\u2022<\/span> Compact, silent design perfect for noise sensitive environments.<\/div>\r\n<div><span>\u2022<\/span> With Zero Touch Provisioning: Plug and play and no setup. Affordable, Easy-to-Use AP for Small Business Networks, with Zero Configuration Required.<\/div>\r\n<div><span>\u2022<\/span> Built-in High-Performance Processor with long life, Suitable for Deployment of Large Scale Commercial Scenarios<\/div>\r\n<div><span>\u2022<\/span> Comes with one-year default warranty \u2013 optionally extendable up to 3 years.<\/div>","sub_category":"Ceiling AP","one_line_des":"COMMANDO AirONE 300Mbps, 2.4GHz, 802.11n, MIMO, Indoor Access Point","part_code":"AIR-AP300"}

Product Highlights : View Details

Hardware
Wireless	802.11n, 2T2R 300Mbps MIMO Technology
Interface	1 * 10/100Mbps WAN Port 1 * 10/100Mbps LAN Port 1* Reset Button to restore factory default 1*DC Port
Antenna	2.4GHz MIMO High Gain omni 5dBi Internal Antenna
Power	DC 12V/1A, PoE: IEEE 802.3af, 48V
Size	168mmX168mmX32mm
Data Rate	300Mbps
Firmware
Operation Mode	Gateway, Repeater, Wireless AP
Network Protocol	IEEE 802.3(Ethernet) IEEE 802.3u(Fast Ethernet) IEEE 802.11ac/n/g/b
Wireless Setting	Wireless Analyzer Distance Control 802.1xACK Time output Multi SSID up to 4 BSSID
Wireless Security	WEP Encryption-64/128/152 bit WPA/WPA2 Personal Encryption (WPA-PSK using TKIP or AES) WPA/WPA2 Enterprise Encryption (WPA-EAP using TKIP) Hide SSID
System Setting	Web-based configuration (HTTP/Telnet)
Firmware Upgrade	Upgrade firmware via web browser or TFTP
Administration Management	Admin User name/Password can be configured
System Monitoring	Device and Networking status statistic
System Log	Support local log, host log, log file exporting
Reset	Reset to factory defaults
Backup	Backup device configuration, then restore this configuration if need
Working Environment
Temperature	Operating Temperature: 0°C~55°C Storage Temperature: -40°C~70°C
Humidity	Working Humidity 5%~95% RH No condensation Storage Humidity 5%~95% RH No condensation
